Carbon Steel Stainless Steel Quartz Sand Filter System Flow Rate 125t/H 180t/H 320t/H 490t/H

Place of Origin Tai'an, Shandong
Brand Name Tonglida
Certification ISO9001 Quality System Certification
Model Number 1T/H-100T/H
Minimum Order Quantity 1 unit
Delivery Time As per requirements

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Pre-treatment For Producing Purified Water, Boiler Feedwater, Industrial Process Water, And Drinking Water. Material Stainless Steel, Carbon Steel, Fiberglass
Brand Tonglida Product Information Quartz Sand Filtration, Activated Carbon Filtration, Manganese Sand Filter, Shallow Bed Sand Filtration, Self-cleaning Filtration, Precision Filtration
Purpose Production Of Purified Water, Boiler Feedwater, Industrial Process Water, And Drinking Water Filtration System
Highlight

stainless steel quartz sand filter

,

125t/h quartz sand filter

,

125t/h activated sand filter
Leave a Message
Product Description





Product Description:

The filtration system is composed of several components including a quartz sand filter, activated carbon filter, manganese sand filter, shallow bed sand filter, self-cleaning filter, and precision filter. The user can select different filter media and filter cartridges with varying degrees of precision depending on their requirements. When under a certain amount of pressure, the system is highly effective in removing various impurities such as suspended solids, organic matter, and colloidal particles from turbid water. Additionally, this filtration system can eliminate odors and colors, making it an efficient solution for purifying water quality.

This type of filtration equipment is widely used among various industries such as power, electronics, beverages, tap water treatment, petroleum, chemicals, metallurgy, textiles, papermaking, food, swimming pools, municipal engineering, and other processes that involve industrial water, domestic water, circulating water, and wastewater treatment.

If your application requires high-quality water, this filtration system is a great choice. By choosing the appropriate filter media and filter cartridges, the system can be customized to fit your specific requirements and efficiently filter out any unwanted impurities.

Inlet pipe diameter Maximum flow rate Drag coefficient Length Weight Power
(mm) (t/h) (mm) (kg) (w)
15 1.8 ≤0.5 150 6 15
25 4.9 ≤0.5 500 10 15
40 12 ≤0.5 500 15 20(40)
50 19 ≤0.5 500 15 20(50)
65 28 ≤0.5 500 15 30(60)
80 50 ≤0.5 500 20 30(60)
100 80 ≤0.5 500 25 50(80)
125 125 ≤0.5 600 35 60(100)
150 180 ≤0.5 600 48 80(120)
200 320 ≤0.5 600 60 100(180)
250 490 ≤0.5 700 78 120(200)
300 710 ≤0.5 700 90 150(240)
350 970 ≤0.5 800 125 200(280)
400 1260 ≤0.5 800 160 250(320)
450 1600 ≤0.5 900 200 300(360)
500 1970 ≤0.5 1000 230 300(400)
600 2850 ≤0.5 1000 265 350
700 3880 ≤0.5 1200 395 450
800 5060 ≤0.5 1200 330 500
900 6410 ≤0.5 1200 380 550



Features:

Pre-treatment is an essential process for producing different types of high-quality water. These water types include purified water, boiler feedwater, industrial process water, and drinking water. The pre-treatment process is necessary to ensure that the water is suitable for its intended usage.

The pre-treatment process usually involves several stages. For purified water, the pre-treatment process may involve sediment filtration, activated carbon filtration, reverse osmosis, and ultraviolet disinfection. For industrial process water, the pre-treatment process may include chemical treatment, sand filtration, and ion exchange.

Pre-treatment for boiler feedwater is crucial to prevent scaling and corrosion in the boiler system. The pre-treatment process may involve clarification, demineralization, and deaeration. Adequate pre-treatment ensures that the boiler system operates efficiently and prolongs its lifespan.

For drinking water, pre-treatment is necessary to ensure that the water is safe for human consumption. The pre-treatment process typically involves coagulation, flocculation, sedimentation, and disinfection. Pre-treatment helps to remove impurities and harmful contaminants such as bacteria, viruses, and chemicals.



Technical Parameters:

Efficient filtration: Meeting on-site filtration requirements is crucial in selecting the right filter media that effectively removes impurities such as suspended solids, organic matter, colloidal particles, microorganisms, and improves water quality. Various filter media options are available, depending on specific needs.



Biological purification: Apart from removing impurities, further degradation of organic matter and harmful substances in water improves the purification effect. Biological purification is particularly vital in obtaining optimal water quality.



Backwash regeneration: The backwashing and regeneration process is essential in restoring the filtering performance of the quartz sand, making continuous water purification possible and ensuring long-term efficiency.



Space-saving: Available in a compact structure and small footprint, this water filtration system can effectively save valuable space, making it ideal for different environments.



Easy installation: Operating and installing this water filtration system is easy and straightforward. It can be directly connected to the inlet and outlet water pipes for immediate use and is designed to have a long service life, which translates to reduced operating costs.



Strong adaptability: The water filtration system offers good adaptability and is suitable for different water qualities and quantities. This makes it a reliable option and eliminates the need to purchase multiple different systems.



Applications:

Industrial Process Water Filtration

Industrial process water requires filtration in order to protect nozzles and heat exchange stations. This is essential for the smooth functioning of various industrial processes.

Industrial Circulating Water Filtration

Industries like steel, metallurgy, papermaking, power generation, petrochemicals, food, and air conditioning systems require filtration of industrial circulating water.

Raw Water Filtration

Filtration is necessary for raw water treatment which includes surface water, rivers, lakes, and seawater. Proper filtration ensures that the water is safe for human consumption and industrial use.

Irrigation Water Filtration

Fields that require irrigation, parks, municipal water supplies, and golf courses require water filtration. Proper filtration ensures that the water quality is suitable for the intended purpose.

Other Water Filtration

Water filtration is also required for aquaculture, swimming pools, and water parks. Different types of filters are used for different purposes.

Multi-industry Application

Water filtration can be applied in various industries such as power, electronics, beverages, petroleum, chemicals, metallurgy, textiles, papermaking, food, swimming pools, and municipal engineering. It is required for industrial water, domestic water, circulating water, and wastewater treatment.
